A revolution

We’re proud to present Zipwake, the new, Dynamic Trim-Control System that’s set to revolutionise the boat world. Featuring an advanced, intuitive control system and a stunning new innovative design, Zipwake delivers a more comfortable ride, better performance and improved fuel consumption – whatever the conditions.

Zipwake seatrials

Zipwake seatrials

Zipwake seatrials

Zipwake seatrials

Zipwake installation

V-shaped interceptors

HIGHLIGHTED STORY

Zipwake Dynamic Trim System is mounted on a 32ft Monza Center Console sport fishing boat to optimize the trim performance. Read more on www.zipwake.com

Zipwake

DYNAMIC
TRIM CONTROL
SYSTEM

CHOOSE COMFORT
ENJOY PERFORMANCE

KEY FEATURES

  • COMFORT AND SAFETY

    Dynamically eliminates uncomfortable and dangerous boat pitch and roll.

  • PERFORMANCE AND FUEL ECONOMY

    Automatically minimizes wave resistance and saves fuel.

  • INTUITIVE AND PRECISE CONTROL

    Innovative 3D controls provide unmatched control of running trim, heel or heading.

  • DURABLE AND EFFECTIVE

    Patented series of durable fast-acting interceptors provide supreme lift force characteristics.

  • COMPLETE AND COMPETITIVE

    All-inclusive mass-produced modular design provides built-in quality, simple installation and easy expansion, whilst making the system affordable.

INTERCEPTORS vs TRIM TABS

  • MORE EFFICIENT LIFT

    Near full beam interceptor arrangements are much more efficient at making lift compared to trim tabs with narrow span.

  • LESS DRAG

    Zipwake’s interceptor blade extends just 30 mm, whereas trim tabs often project 150 mm reflecting substantial drag.

  • 5 TIMES FASTER ACTUATION

    Zipwake’s blade stroke takes 1.5 seconds, outperforming conventional trim tabs by at least a factor of 5.

  • LESS WAKE

    Interceptors provide more effective trim control creating less waves which directly leads to better fuel economy.

ALL IN A BOX

A Kit Box includes all parts needed to install a Dynamic Trim Control System with one pair of fast-acting straight interceptors. There are four different Kit Boxes, one for each interceptor length.

Any base installation can be expanded with up to two extra pairs of Series S interceptors, thus allowing a total of six interceptors without any need for additional connectors or power supply.


V-SHAPED INTERCEPTORS

We are proud to present our latest ”world’s first” - mass produced V-shaped interceptors. They make the successful Series S even more versatile and highly competitive. V-shaped interceptors for centerline mounting are perfect for filling the gap between twin outboards or sterndrives, as well as dual propeller tunnels.

The four V-shaped models cover deadrise angles
effectively between 11 to 24 degrees.

V-shaped centerline mounted interceptors can be included in new installations, or retro-fitted to already installed systems.
The modular design enables boat designers to develop their own novel applications, e.g. in multihulls or stepped high- speed craft.

MADE IN SWEDEN

THE STORY OF ZIPWAKE

Zipwake started with a vision. In this case, to develop and bring to the motorboat world new, complete and highly competitive solutions to the well-known trim problems of planing and semi-planing boats. In 2011, a carefully selected team of engineers with solid knowledge and experience from both the marine and automotive industry was put together.

After three and a half years of intense product development, the first Zipwake Dynamic Trim Control system, the Series S, was launched in Amsterdam in November at METS 2014.

References

44 Eastbay SX

Zipwake 2 x 750S

Reference boat specification: Length 46 feet ( 14.30 m ), Beam 14.6 feet ( 4.40 m ), Weight 18 000 kg, Engine Volvo Penta IPS Max. speed 33 knots

layer layer layer

44 Eastbay SX

Zipwake 2 x 750S

AB 100

Zipwake 2 x 750S, 2 x 600S, 2 x 450S

Reference boat specification: Length 100 feet ( 30,50 m ), Beam 22 feet ( 6,80 m ), Weight 90 000 kg, Engine 3 x MAN V12, 1 900hp each, Max. speed 54 knots

layer layer layer

AB 100

Zipwake 2 x 750S, 2 x 600S, 2 x 450S

Anytec 750 SPD

Zipwake 2 x 450S

Reference boat specification: Length 26 feet ( 8.08 m ), Beam 7.6 feet ( 2.32 m ), Weight 1 500 kg, Engine Yamaha 300 hp, Max. speed 50 knots

layer layer layer

Anytec 750 SPD

Zipwake 2 x 450S

Aquador 23DC

Zipwake 2 x 450S

Reference boat specification: Length 23 feet ( 7.15 m ), Beam 8 feet ( 2.56 m ), Weight 1 750 kg, Engine Mercruiser 5,0 Max. speed 37 knots

layer layer layer

Aquador 23DC

Zipwake 2 x 450S

Askeladden C65 Cruiser

Zipwake 2 x 300S

Reference boat specification: Length 21 feet ( 6.45 m ), Beam 8 feet ( 2.46 m ), Weight 1 700 kg, Engine Suzuki 200hp, Max. speed 40 knots

layer layer layer

Askeladden C65 Cruiser

Zipwake 2 x 300S

Askeladden P77

Zipwake 2 x 450S

Reference boat specification: Length 25 feet ( 7.7 m ), Beam 8.2 feet ( 2.50 m ), Weight 1800 kg, Engine Suzuki, Max. speed 34 knots

layer layer layer

Askeladden P77

Zipwake 2 x 450S

Atlantic Marine 730S

Zipwake 2 x 600S

Reference boat specification: Length 23 feet ( 7.30 m ), Beam 8 feet ( 2.50 m ), Weight 2 000 kg, Engine Mercury Verado 250 hk, Max. speed 38 knots

layer layer layer

Atlantic Marine 730S

Zipwake 2 x 600S

Bayliner 2859

Zipwake 4 x 450S

Reference boat specification: Length 29 feet ( 8.80 m ), Beam 10 feet ( 3.00 m ), Weight 3 900 kg, Engine Mercruiser 5.7 LX V8, Max. speed 35 knots

layer layer layer

Bayliner 2859

Zipwake 4 x 450S

Beneteau Barracuda 8

Zipwake 2 x 300S

Reference boat specification: Length 26 feet ( 7.99m ), Beam 12,6 feet ( 2.78 m ), Weight 2 645 kg, Engine 2 x Suzuki 150hp Outboard Max. speed 35 knots

layer layer layer

Beneteau Barracuda 8

Zipwake 2 x 300S

Boghammar 32 Magnum

Zipwake 2 x 300S + 1 x 300S

Reference boat specification: Length 32 feet ( 10 m ), Beam 8.5 feet ( 2,6 m ), Weight 3 500kg, Engine 2 x Mercruiser, Max. speed +40 knots

layer layer layer

Boghammar 32 Magnum

Zipwake 2 x 300S + 1 x 300S

Broson 070

Zipwake 2 x 600S

Reference boat specification: Length 26 feet ( 8.00 m ), Beam 9 feet ( 2.75 m ), Weight 3000 kg, Engine VP D4, Max. speed 40 knots

layer layer layer

Broson 070

Zipwake 2 x 600S

Broson 8M SSRB

Zipwake 2 x 450S

Reference boat specification: Length 26 feet ( 8.00 m ), Beam 9 feet ( 2.75 m ), Weight 3000 kg, Engine VP D4, Max. speed 40 knots

layer layer layer

Broson 8M SSRB

Zipwake 2 x 450S

Broson X90

Zipwake 2 x 600S + 2 x 450S

Reference boat specification: Length 36 feet ( 11.20 m ), Beam 13feet ( 3.95 m ), Weight 7 000 kg, Engine VP D6, Max. speed 32 knots

layer layer layer

Broson X90

Zipwake 2 x 600S + 2 x 450S

Broson X90

Zipwake 2 x 600S

Reference boat specification: Length 40 feet ( 12.50 m ), Beam 13 feet ( 3.95 m ), Weight 11 000 kg, Engine 2 x VP D6, Max. speed 40 knots

layer layer layer

Broson X90

Zipwake 2 x 600S

Caribbean 24 FBSF

Zipwake 2 x 450S

Reference boat specification: Length 28 feet ( 8.50 m ), Beam 8.80 feet ( 2.7 m ), Weight 3 000 kg, Engine Mercruiser, Max. speed 30 knots

layer layer layer

Caribbean 24 FBSF

Zipwake 2 x 450S

Cobrey 28SC

Zipwake 2 x 450S

Reference boat specification: Length 28 feet ( 8.80 m ), Beam 8.4 feet ( 2.55 m ), Weight 2 850 kg, Engine Mercruiser 4.5L 250hp Max. speed 35 knots

layer layer layer

Cobrey 28SC

Zipwake 2 x 450S

Doqueve 300

Zipwake 2 x 600S + 2 x 300S

Reference boat specification: Length 26 feet ( 8.00 m ), Beam 10 feet ( 3.00 m ), Weight 3 500 kg, Engine 2 x Yanmar D6, Max. speed 28 knots

layer layer layer

Doqueve 300

Zipwake 2 x 600S + 2 x 300S

Epoca open

Zipwake 2 x 300S

Reference boat specification: Length 26 feet ( 8 m ), Beam 9.38 feet ( 2.86 m ), Weight 2 150 kg, Engine Mercury Verado 250hp, Max. speed 44 knots

layer layer layer

Epoca open

Zipwake 2 x 300S

Epoca sport

Zipwake 2 x 300S

Reference boat specification: Length 26 feet ( 8 m ), Beam 9.38 feet ( 2.86 m ), Weight 2 250 kg, Engine Volvo Penta D3-200hp, Max. speed 35 knots

layer layer layer

Epoca sport

Zipwake 2 x 300S

Fairline 57

Zipwake 6 x 600S

Reference boat specification: Length 57 feet ( 17.5 m ), Beam 16 feet ( 4.75 m ), Weight 22 000 kg, Engine 2 x VP D12 Max. speed 30 knots

layer layer layer

Fairline 57

Zipwake 6 x 600S

Fairline Phantom 40

Zipwake 4 x 600S

Reference boat specification: Length 40 feet ( 12.00 m ), Beam 13 feet ( 3.95 m ), Weight 11 600 kg, Engine 2 x VP D6, Max. speed 35 knots

layer layer layer

Fairline Phantom 40

Zipwake 4 x 600S

Flipper 605 WA

Zipwake 2 x 450S

Reference boat specification: Length 20 feet ( 6.15 m ), Beam 7.6 feet ( 2.32 m ), Weight 1 000 kg, Engine Mercury 115hp, Max. speed 37 knots

layer layer layer

Flipper 605 WA

Zipwake 2 x 450S

Formula 31 PC

Zipwake 2 x 600S

Reference boat specification: Length 34 feet ( 10,40 m ), Beam 11 feet ( 3.35 m ), Weight 5 500kg, 2 x Mercruiser 250 hp , Max. speed 35 knots

layer layer layer

Formula 31 PC

Zipwake 2 x 600S

Gozzi 24

Zipwake 2 x 300S

Reference boat specification: Length 24 feet ( 7.30 m ), Beam 7.85 feet ( 2.40 m ), Weight 1 600 kg, Engine Yamaha 350hp, Max. speed 58 knots

layer layer layer

Gozzi 24

Zipwake 2 x 300S

Greenline 33

Zipwake 4 x 450S

Reference boat specification: Length 33 feet ( 10 m ), Beam 11.48 feet ( 3.50 m ), Weight 4 500 kg, Engine VW TDI 115hp, Max. speed 15 knots

layer layer layer

Greenline 33

Zipwake 4 x 450S

Ibiza 26 Touring

Zipwake 2 x 450S

Reference boat specification: Length 26 feet ( 8 m ), Beam 8.5 feet ( 2.6 m ), Weight 3 000 kg, Engine Suzuki 300hp, Max. speed 40 knots

layer layer layer

Ibiza 26 Touring

Zipwake 2 x 450S

Marell 850

Zipwake 2 x 600S

Reference boat specification: Length 29 feet ( 8.80 m ), Beam 10 feet ( 3 m ), Weight 2 200 kg, Engine 2 x Evinrude 250hp, Max. speed 58 knots

layer layer layer

Marell 850

Zipwake 2 x 600S

Marex 330

Zipwake 2 x 600S + 2 x 300S

Reference boat specification: Length 33 feet ( 10.30 m ), Beam 10.7 feet ( 3.30 m ), Weight 5 200 kg, Engine 1 x VP KAD 32, Max. speed 30 knots

layer layer layer

Marex 330

Zipwake 2 x 600S + 2 x 300S

Marex 375

Zipwake 2 x 600S

Reference boat specification: Length 40 feet ( 12 m ), Beam 11.6 feet (3.55 m ), Weight 7 700 kg, Engine VP D6 400hp, Max. speed 35 knots

layer layer layer

Marex 375

Zipwake 2 x 600S

Minor 31

Zipwake 2 x 450S

Reference boat specification: Length 31 feet ( 9.50 m ), Beam 10.5 feet ( 3.20 m ), Weight 5 000kg, Engine 1 x VP D6 370hp, Max. speed 35 knots

layer layer layer

Minor 31

Zipwake 2 x 450S

Monark 66

Zipwake 2 x 450S + 2 x 300S

Reference boat specification: Length 21 feet ( 6.50 m ), Beam 8 feet ( 2.50 m ), Weight 1 300 kg, Engine 1 x VP AQ 130, Max. speed 25 knots

layer layer layer

Monark 66

Zipwake 2 x 450S + 2 x 300S

Nimbus 230R

Zipwake 2 x 600S

Reference boat specification: Length 23 feet ( 7.10 m ), Beam 7.8 feet ( 2.40m ), Weight 1 850kg, Engine 1 x VP 5.7 GXI, Max. speed 40+ knots

layer layer layer

Nimbus 230R

Zipwake 2 x 600S

Nimbus 250R

Zipwake 2 x 750S

Reference boat specification: Length 25 feet ( 7.50 m ), Beam 8 feet ( 2.60 m ), Weight 2 500 kg, Engine Volvo Penta KAD32 Max. speed 35 knots

layer layer layer

Nimbus 250R

Zipwake 2 x 750S

Nimbus 26 Nova

Zipwake 2 x 450S

Reference boat specification: Length 26 feet ( 8 m ), Beam 8.8 feet ( 2.7 m ), Weight 2 500 kg, Engine VP KAD44 alt D4, Max. speed 35 knots

layer layer layer

Nimbus 26 Nova

Zipwake 2 x 450S

Nordkapp 760

Zipwake 2 x 450S

Reference boat specification: Length 26 feet ( 8.10 m ), Beam 8 feet ( 2.50 m ), Weight 1 900 kg, Engine 1 x Evinrude 200 HP, Max. speed 42 knots

layer layer layer

Nordkapp 760

Zipwake 2 x 450S

Nordwest 420 Fly

Zipwake 2 x 750S + 2 x 300S

Reference boat specification: Length 42 feet ( 13.50 m ), Beam 13 feet ( 3.90 m ), Weight 12 000 kg, Engine 2 x VP D6, Max. speed 32 knots

layer layer layer

Nordwest 420 Fly

Zipwake 2 x 750S + 2 x 300S

Nordwest 420 Fly IPS

Zipwake 2 x 750S + 2 x 600S

Reference boat specification: Length 42 feet ( 13.50 m ), Beam 13 feet ( 3.90 m ), Weight 12 000 kg, Engine 2 x VP D6 IPS, Max. speed 35 knots

layer layer layer

Nordwest 420 Fly IPS

Zipwake 2 x 750S + 2 x 600S

Palm Beach 42

Zipwake 2 x 750S + 2 x 450S

Reference boat specification: Length 43 feet ( 13 m ), Beam 14.6 feet ( 4.5 m ), Weight 11 500 kg, Engine Volvo Penta, Straight shaft Max. speed 35 knots

layer layer layer

Palm Beach 42

Zipwake 2 x 750S + 2 x 450S

Palm Beach 42

Zipwake 2 x 750S + 2 x 450S

Reference boat specification: Length 43 feet ( 13 m ), Beam 14.6 feet ( 4.5 m ), Weight 11 500 kg, Engine Volvo Penta IPS Max. speed 36 knots

layer layer layer

Palm Beach 42

Zipwake 2 x 750S + 2 x 450S

Palm Beach 50

Zipwake 2 x 750S

layer layer layer

Palm Beach 50

Zipwake 2 x 750S

Princess 388

Zipwake 2 x 300S + 2 x 450S + 2 x 750S

Reference boat specification: Length 41 feet ( 12.40 m ), Beam 14 feet ( 4.10 m ), Weight 9 500 kg, Engine 2 x VP TAMD 61, Max. speed 27 knots

layer layer layer

Princess 388

Zipwake 2 x 300S + 2 x 450S + 2 x 750S

Princess P52

Zipwake 2 x 750S + 2 x 600S

Reference boat specification: Length 52 feet ( 15.85 m ), Beam 14.6 feet ( 4.47 m ), Weight 24 000 kg, Engine Volvo Penta, Straight shaft, Max. speed 30 knots

layer layer layer

Princess P52

Zipwake 2 x 750S + 2 x 600S

Riviera 45 Open Flybridge

Zipwake 4 x 300S

Reference boat specification: Length 51,5 feet ( 15,66 m ), Beam 15, feet ( 4.80 m ), Weight 17 850 kg, Engine Caterpillar C8.7 x2 , Max. speed 30 knots

layer layer layer

Riviera 45 Open Flybridge

Zipwake 4 x 300S

Rocad 498

Zipwake 2 x 300S

Reference boat specification: Length 16 feet ( 4.98 m ), Beam 6,56 feet ( 2 m ), Weight 400 kg, Engine Suzuki 60hp outboard, Max. speed 25 knots

layer layer layer

Rocad 498

Zipwake 2 x 300S

Ryds 23WA

Zipwake 4 x 300S

Reference boat specification: Length 23 feet ( 7.35 m ), Beam 8 feet ( 2.35 m ), Weight 2 000 kg, Engine Mercruiser 4.3 MPI, Max. speed 37 knots

layer layer layer

Ryds 23WA

Zipwake 4 x 300S

Ryds 628 Mid C

Zipwake 2 x 300S

Reference boat specification: Length 21 feet ( 6.25 m ), Beam 7.6 feet ( 2.34 m ), Weight 720kg, Engine Mercury 150hp, Max. speed 44 knots

layer layer layer

Ryds 628 Mid C

Zipwake 2 x 300S

Sealine F530

Zipwake 2 x 750S + 2 x 600S

Reference boat specification: Length 53 feet ( 15.94 m ), Beam 15.2 feet ( 4.63 m ), Weight 16 500 kg, Engine Volvo Penta IPS600 , Max. speed 26 knots

layer layer layer

Sealine F530

Zipwake 2 x 750S + 2 x 600S

Skilsö 34 Panorama

Zipwake 2 x 450S

Reference boat specification: Length 34 feet ( 10.25 m ), Beam 11,35 feet ( 3.95 m ), Weight 5 500 kg, Engine Yanmar 8LV 370 370hk Max. speed 27 knots

layer layer layer

Skilsö 34 Panorama

Zipwake 2 x 450S

SSRS 11M

Zipwake 2 x 600S

Reference boat specification: Length 38 feet ( 11.6 m ), Beam 13 feet ( 4 m ), Weight 6 000 kg, Engine 2 x 300hp Suzuki outboards, Max. speed 34 knots

layer layer layer

SSRS 11M

Zipwake 2 x 600S

Steber 1050

Zipwake 2 x 600S + 2 x 450S

Reference boat specification: Length 34 feet ( 10,40 m ), Beam 12,6 feet ( 3.84 m ), Weight 9 000 kg, Engine Caterpillar C7 , Max. speed 20 knots

layer layer layer

Steber 1050

Zipwake 2 x 600S + 2 x 450S

Storebro 465 Biscay

Zipwake 2 x 600S + 2 x 300S

Reference boat specification: Length 46 feet ( 14.20 m ), Beam 13 feet ( 4.10 m ), Weight 12 000 kg, Engine 2 x VP TAMD 74, Max. speed 32 knots

layer layer layer

Storebro 465 Biscay

Zipwake 2 x 600S + 2 x 300S

Targa 27.1

Zipwake 2 x 450S + 2 x 300S

Reference boat specification: Length 27 feet ( 8.40m, ) Beam 10 feet ( 3 ), Weight 3 900kg, Engine 1 x VP D6 370hp, Max. speed 36 knots

layer layer layer

Targa 27.1

Zipwake 2 x 450S + 2 x 300S

Targa 44

Zipwake 2 x 600S

Reference boat specification: Length 47 feet ( 14.36 m ), Beam 13 feet ( 3.95 m ), Weight 10 000 kg, Engine Volvo Penta D6 / IPS, Max. speed 39 knots

layer layer layer

Targa 44

Zipwake 2 x 600S

Uttern S51

Zipwake 2 x 450S

Reference boat specification: Length 16 feet ( 5 m ), Beam 6.8 feet ( 2.08 m ), Weight 690 kg, Engine Mercury Max. speed 38 knots

layer layer layer

Uttern S51

Zipwake 2 x 450S

Viknes 1080

Zipwake 2 x 450S + 2 x 300S

Reference boat specification: Length 38 feet ( 11.55 m ), Beam 12 feet ( 3.59 m ), Weight 8 400 kg, Engine Yanmar, Straight shaft Max. speed 30 knots

layer layer layer

Viknes 1080

Zipwake 2 x 450S + 2 x 300S

Windy 29 Coho

Zipwake 2 x 450S

Reference boat specification: Length 29 feet ( 8.85 m ), Beam 8.85 feet ( 2.70 m ), Weight 3 250 kg, Engine Volvo Penta, Max. speed 45 knots

layer layer layer

Windy 29 Coho

Zipwake 2 x 450S

XO 360

Zipwake 2 x 450S

Reference boat specification: Length 36 feet ( 11 m ), Beam 10.8 feet ( 3,29 m ), Weight 5 300 kg, Engine Volvo Penta D6 2 x 370hp, Max. speed 45 knots

layer layer layer

XO 360

Zipwake 2 x 450S

Yamarin 81DC

Zipwake 2 x 450S

Reference boat specification: Length 27 feet ( 8.00 m ), Beam 13 feet ( 2.76m ), Weight 1 950 kg, Engine Yamaha 300hp, Max. speed 40 knots

layer layer layer

Yamarin 81DC

Zipwake 2 x 450S

Yuka 12mt Lobster

Zipwake 2 x 600S + 2 x 300S

Reference boat specification: Length 40 feet ( 8.00 m ), Beam 13 feet ( 3.8 m ), Weight 9 000kg, Engine 2 x Yanmar 220hp Bravo2, Max. speed 36 knots

layer layer layer

Yuka 12mt Lobster

Zipwake 2 x 600S + 2 x 300S

Support

The team

Zipwake is a new Swedish marine brand and company fully committed to the large scale enhancement of ride comfort and dynamic performance of boats. It is our mission to design and produce affordable motion-control equipment that combines cutting-edge technology with intuitive robust design.

Lorentz Simonson

Lorentz Simonson

CEO

lorentz@zipwake.com
+46 (0)768 15 63 40

Niclas Olofsson PhD

Niclas Olofsson PhD

Product Manager

hello@zipwake.com
+46 (0)31 24 77 75

Henrik Kuhlman

Henrik Kuhlman

Area Sales Manager

henrik@zipwake.com
+46 (0)725 22 75 77

Göran Fredin

Göran Fredin

Area Sales Manager

goran.fredin@zipwake.com
+46 (0)732 66 11 11

Marie Gillberg

Marie Gillberg

Accountant

hello@zipwake.com
+46 (0)31 24 77 75

Tiia-Mai Truup

Tiia-Mai Truup

Logistics

tiia-mai@zipwake.com
+46 (0)31 24 77 75

Map

Distributors

Contact our distributors

Distributors

Distributor
Dealer
